6.8 inch IPS TFT LCD Module with 480RGBx1280 Resolution and MIPI Interface

Name: 68 inch IPS TFT LCD Module with 480RGBx1280 Resolution and MIPI Interface
Brand: HuaXin
Price: 1 USD

Buy cheap 6.8 inch IPS TFT LCD Module with 480RGBx1280 Resolution and MIPI Interface product

Model Number : HX686006A

interface : MIPI

MOQ : 1000

Delivery Time : 6weeks~8weeks

view angle : ALL 0' clock

Brand Name : HuaXin

Packaging Details : blister+foam box+bubble bag+inside carton+master carton

Payment Terms : T/T

name : TFT LCD MODULE

Driving IC : FL7705

Supply Ability : 100K per month

Display Technology : IPS TFT

Certification : ISO14001/ISO9001/IATF16949

Price : negotiation

size : 6.8"

resolution : 480(RGB)*1280

Place of Origin : China

Contact Now

6.8 inch IPS TFT LCD Module with 480RGBx1280 Resolution and MIPI Interface,650 brightness Driving IC FL7705 12LEDS

Product Specifications

Part NO.	HX686006A
Display Technology	IPS TFT LCD
Diagonal Screen Size	6.8inch
Active Area (mm)	60.22(H)X160.59(V)
Panel size(mm)	78.7(H)X189.6(V)X7.5(T)
Brightness(cd/m2)	650
Resolution	480(RGB)*1280
Interface	MIPI
View angle	ALL o'clock
Driving IC	FL7705

Product Picture

6.8 inch IPS TFT LCD Module with 480RGBx1280 Resolution and MIPI Interface

Technical Drawing

6.8 inch IPS TFT LCD Module with 480RGBx1280 Resolution and MIPI Interface

TFT Technology Overview

Manufacturer Information

Huaxin Technology (Enshi) Co., LTD
Located in Hubei, Enshi | Founded: 2009
High-technology enterprise specializing in R&D, production, and sales of LCD, LCM, TFT, backlight, and OLED displays

Company Advantages:

Cost-effective factory base in inland city
Advanced equipment for stable quality
Automated processes for efficiency and consistency
Expert engineering team with 20+ years experience
Custom product design capabilities

Certifications: ISO14001, ISO9001, IATF16949, SGS for LCD modules

Product Portfolio:

LCD: VA, TN, HTN, STN, FSTN, CSTN series
LCM: COB, TBA, COG, TP, LED backlight series

Company Statistics:

Registered capital: 20 million
Current staff: 500+ employees
R&D accounts for 10% of workforce
QC accounts for 15% of workforce

Production Capacity

Product Type	2021	2022	2023	2024	2025	Unit
LCD Production	4.5	9	9	9	9	Thousands of logarithms/Day
LCM Production	70	150	300	450	450	Thousand pieces/Day
Backlight Production	100	200	300	500	500	Thousand pieces/Day
OLED Production	10	20	30	40	50	Thousand pieces/Day

Product Applications

Car navigation systems & printers
Video call systems & advertising displays
Automotive & medical devices
Fitness equipment & handheld devices
Industrial control systems & home appliances

TFT Display Advantages

Excellent image quality with high resolution, sharpness, and color accuracy
Fast response times for quick pixel switching
Wide viewing angles with minimal color shifts
Energy-efficient operation
Available in various sizes from small handheld to large panel displays
LED backlighting for screen illumination
Wide range of applications across multiple industries

TFT Display Limitations

Limited viewing angles compared to some technologies
Limited contrast ratio
Backlighting requirements and power consumption
Response time limitations and potential motion blur
Limited flexibility in display form factors
Limited color gamut range
